5-Port Fast Ethernet Unmanaged Desktop Switch
Nereden Alınır


The DES-1005D 5-Port Fast Ethernet Unmanaged Desktop Switch is a five port fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-1005D to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.
Auto-Sensing 10/100 Ports
The DES-1005D 5-Port Fast Ethernet Unmanaged Desktop Switch uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.
Auto MDI/MDIX Crossover
All ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.
Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full. This gives you a more reliable connection for all of your connected devices.

Genel Özellikler

Key Features
• Inexpensive Fast Ethernet solution for Home/SOHO
• Five 10/100 Mbps Fast Ethernet ports
• Auto MDI/MDIX crossover for all ports
• Store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• IEEE 802.3x Flow Control
• Plug-and-play installation
• RoHS compliant
Switching Fabric
• 1.0 Gbps switching fabric
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x flow control
Data Transfer Rates
• Ethernet:
   10 Mbps (half duplex)
   20 Mbps (full duplex)
• Fast Ethernet:
   100 Mbps (half duplex)
   200 Mbps (full duplex)
• Star
Media Interface Exchange
• Auto MDI/MDIX adjustment for all ports
Network Cables
• 10BASE-T:
   UTP CAT 3/4/5/5e (100 m max.)
   EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX:
   UTP CAT 5/5e (100 m max.)
   EIA/TIA-568 100-ohm STP (100 m max.)
LED Indicators
• Per port: Link/Activity
• Per device: Power
Transmission Method
• Store-and-forward
MAC Address Table
• 2K entries per device
MAC Address Learning
• Automatic update
Packet Filtering/Forwarding Rates
• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
RAM Buffer
• 48 KB per device
DC Input
• External 5 V / 1 A power adapter
Power Consumption
• Power On (Standby):
   DC input: 0.4 watts
   AC input: 0.9 watts
• Maximum:
   DC input: 2.18 watts
   AC input: 2.5 watts
Heat Dissipation
• Power On (Standby):
   AC input: 2.728 BTU/h
• Maximum:
   AC input: 8.528 BTU/h
Operating Temperature
• 0 to 50 ˚C (32 to 122 ˚F)
Storage Temperature
-10 to 70 ˚C (14 to 158 ˚F)
Operating Humidity
• 10% to 90% RH non-condensing
Storage Humidity
• 5% to 90% RH non-condensing
Device Dimensions (W x D x H)
• 125.3 x 83.4 x 29.1 mm (5.0 x 3.3 x 1.2 inches)
• FCC Class B
• ICES-003 Class B
• CE Class B
• C-Tick Class B
• VCCI Class B
• cUL
• CB

Fiziksel Özellikler


Sipariş Bilgisi

DES-1005D  5-Port Fast Ethernet Unmanaged Desktop Switch


Back view
Front view
