תכונות המוצר:
מצלמת מעקב רשת באיכות HD עם תמיכה ב - PoE
מאפיינים כללים:

Hardware profile camera
• Megapixel 1/4-inch CMOS-sensor
• Lens with a focal length of 2,8-12 mm
• Aperture : F1.4
• Built-in ICR filter
• Shutter speed: 1/5 to 1 /10, 000 sec
• Min. illumination : 0.1 Lux ( color mode ), 0.05 Lux ( B / W )
• Angles:
  • 77,5-22,7 ( horizontal)
  • 53,3-14,5 ( vertical)
  • 82,5-27 ( diagonal)
• Minimum Object Distance : 0.2 m

Image characteristics
• Setting the image size and quality , frame rate and bit rate
• The timings and paste text
• 3 configurable motion detection windows
• 5 customizable zones of private masks
• Adjust brightness , color saturation , contrast and sharpness

Video compression
• Compression formats H.264/MPEG-4/MJPEG
• Multicast streaming video formats H.264/MPEG-4
• JPEG for still images

Video resolution
• 16:9 - 1280 x 800 , 1280 x 720 , 800 x 450 , 640 x 360 , 480 x 270 , 320 x 176 up to 30 kadrov/s1
• 4:3 - 1024 x 768 , 800 x 600 , 640 x 480 , 480 x 360 , 320 x 240 up to 30 kadrov/s1

Audio support
• Audio Encoding MPEG- 4 AAC, transfer rate : 16 kbit / s to 128 kbit / s
• Audio Coding G.711, bit rate: 8 kbit / s to 64 kbit / s

Interfaces to external devices
• Port 10/100 BASE-TX Fast Ethernet
• Supports 802.3af PoE
• Connectors DI / DO for external devices
• RS- 485 port for connecting external devices / tilt
• Card slot Micro SD / SDHC
• External audio-vhod/vyhod

Network protocols
• IPv4
• IPv6
• TCP / IP
• UDP
• ICMP
• DHCP- Client
• NTP- Client (D-Link)
• DNS- client
• DDNS- Client (D-Link)
• SMTP- client
• FTP- client
• HTTP / HTTPS
• 802.1x
• Samba- client
• PPPoE
• UPnP port forwarding
• RTP / RTSP / RTCP
• Filtering IP- addresses
• QoS
• CoS
• Multicast
• IGMP
• ONVIF
• SNMP v1/v2/v3

Safety
• Security administrator account and user groups
• Password authentication
• HTTPS encryption to access the web-based interface
• HTTP and RTSP authentication

System requirements for the web-based interface
• Web-browser : Internet Explorer, Firefox, Chrome

Event management
• Motion detection
• Event notification and download stop-kadrov/videoklipov via email or FTP
• Support for multiple SMTP servers , and FTP
• Multiple event notifications
• Several ways to create backups

Remote management
• Create stop-kadrov/videoklipov and save to a local hard disk through Web-browser
• Interface settings , available through the web- browser

System Requirements D-ViewCam ™
• Operating System : Microsoft Windows 8/7/Vista/XP
• Web- browser : Internet Explorer 7 or above
• Protocol : Standard TCP / IP

Software features D-ViewCam ™
• Remote management / control of up to 32 cameras
• Viewing images on a single screen : up to 32 cameras
• Recording Options for triggering a sensor or manually
• Supports all management functions available through the Web-based interface


נתונים פיזיים

Weight
• 150 grams

Power
• 12 VDC, 1.5 A, 802.3af PoE

Power consumption
• Max. 2.88 W (PoE)

Temperature
• Operating: 0 to 40 C
• Storage: -20 to 70 C

Humidity
• Operating: 20% to 80% (non-condensing)
• Storage: 5% to 95% (non-condensing)

Certifications
• CE
• CE LVD
• FCC
• C-Tick
